Kohler PA-KT745-3008 PRO Series Lawn Mower Engine KT745 1-1/8” x 4.29" Crankshaft

Kohler KT745-3008 Vertical 7000 Series V-Twin Engine, Replaces KT730-3025

Not Available to Ship to California

Kohler KT745-3008 Vertical Twin Cylinder 7000 Series Engine, 1.125" x 4.3" Crankshaft, 747cc, 26 HP, Bendix Drive Electric Start, Heavy Duty Air Cleaner

Pressure lubrication extends engine life by keeping critical components well-lubricated

Consistent-Cut technology maintains engine speed for a cleaner turf cut, even in tall, wet grass

Easy, reliable starting in all conditions

Engineered and assembled in the USA





View the Owner's Manual HERE

View the Service Manual HERE

ENGINE SPECIFICATIONS
ENGINE BRAND	Kohler
MODEL NUMBER
WARRANTY	3 Year Commercial & Consumer
POWER OUTPUT	26 HP
TORQUE	42.4 ft-lb @ 2600 RPM
CRANKSHAFT ORIENTATION	Vertical
CRANKSHAFT TYPE
CRANKSHAFT DIAMETER	1.125"
CRANKSHAFT LENGTH	4.3"
END TAPPED SIZE
KEYWAY
ROTATION DIRECTION
STARTER TYPE	Bendix Drive Electric
IGNITION SYSTEM	RFI
CARBURETOR
NUMBER OF CYLINDERS	Two
CYLINDER BORE	Cast Iron Liners
AIR CLEANER	Heavy Duty
OIL CAPACITY	2 qt
FUEL	Gasoline
FUEL PUMP
GOVERNOR SYSTEM
CONTROLS	Dual
BORE x STROKE	3.3" x 2.7"
COMPRESSION RATIO	9.1 : 1
CHARGING SYSTEM
MUFFLER
FLYWHEEL
REPLACES	KT730-3025, KT740-3041, KT740-3049, KT745-3088, KT745-3089
ENGINE NOTES

Please verify this is the correct replacement engine using your current engine's model and spec number. Do not order based off the image alone - engines in the same series may look similar, but have different specifications that may not work for your application. If you're unsure if this is the correct replacement, don't hesitate to contact us via an eBay message with your current model and spec numbers and we'll do our best to find the engine that works for you.

Includes Kohler Warranty - Please note, if you should have any problems with engine after installation and start-up you will need to contact your local Kohler dealer.  Return shipping to us is not covered by Kohler's warranty. Please contact us if you have any questions regarding warranty.

ONLY returns on engines that have not been mounted, had oil added, or hooked up to fuel will be accepted. Buyer is responsible for return shipping and getting engine back to us undamaged, this means packing up safely and securely.

NEW ENGINE NOTES: 1) Engine Has No Oil, You Must Add Before Starting!  2) Engine mounting holes are not tapped, you will have to tap prior to installing.
